Number of wires : 7
Number of terminals : 7
Alternator : White Between each White = 0.9 ohms+/-20%
Alternator : White to Ground = O.L. ON DISPLAY
Pickup : Red to White= 500 ohms+/-20%
Source : Green to Black = 300 ohms+/-20%
Before installing your new stator
Our stator may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation; we suggest as close as possible no less than 0.010″.
